SS-31 (Elamipretide): A Mitochondria-Targeting Peptide in In Vitro Studies

Key takeaways

SS-31 (elamipretide) is an aromatic-cationic tetrapeptide studied in vitro for its interaction with the inner mitochondrial membrane.
It associates with cardiolipin, a lipid concentrated in that membrane.
This targeting makes it a reference compound for mitochondrial research in cell models.
Studied in assays of mitochondrial function and membrane integrity.
Supplied as a lyophilized powder for in vitro research use only.

SS-31 (Elamipretide): A Mitochondria-Targeting Peptide

The mitochondrion is far more than just the "powerhouse of the cell." It is a dynamic hub for metabolic signaling, a primary source of reactive oxygen species (ROS), and a key regulator of cellular life and death. As our understanding of mitochondrial dysfunction in various disease models has grown, so has the demand for precise chemical tools to study and modulate mitochondrial activity. In this context, a novel class of compounds known as mitochondria-targeting peptides has emerged, and among them, SS-31 (also known as Elamipretide) is one of the most well-characterized and significant.

This article provides a detailed technical overview of the ss-31 peptide, exploring its unique structure, its fascinating mechanism of targeting the inner mitochondrial membrane, and its applications as a tool for in vitro research. All information presented is for a qualified scientific audience within the strict confines of "Research Use Only" (RUO) laboratory applications.

SS-31, SS31 peptides, elamipretide: which name is right?

All of them refer to one compound. "SS-31" and "SS31" are the same series name (SS for Szeto-Schiller, 31 for the series position), elamipretide is the International Nonproprietary Name, and MTP-131 is an earlier development code. Searches for "ss31 peptides" and "ss-31 peptide" land on the same tetrapeptide, D-Arg-Dmt-Lys-Phe-NH₂, CAS 736992-21-5. The naming history and the identifiers to check on a COA are laid out in SS31 peptides, SS-31 and elamipretide: one compound, several names.

The Unique Structure of SS-31

Unlike large protein hormones or complex ligands, SS-31 is a relatively simple yet elegant molecule. It is a small, water-soluble tetrapeptide, composed of just four amino acids.

Sequence: D-Arg-Dmt-Lys-Phe-NH2
CAS Number: 736992-21-5
Molecular Formula: C₃₂H₄₉N₉O₅
Molecular Weight: 639.8 g/mol

The key to its function lies in its specific structure, known as an aromatic-cationic motif.

Cationic Residues: It contains two positively charged (cationic) amino acids, D-Arginine and Lysine.
Aromatic Residues: It contains two aromatic amino acids, Phenylalanine and, most importantly, Dimethyltyrosine (Dmt), a synthetic amino acid that plays a crucial role in its antioxidant properties.

The alternating nature of these aromatic and cationic groups allows the ss-31 molecule to possess unique physicochemical properties, including the ability to cross cell membranes without the need for a transporter or receptor.

The Mechanism: Targeting the Inner Mitochondrial Membrane

The most remarkable aspect of SS-31 is its mechanism of action, which bypasses conventional cell surface receptors entirely. This is central to understanding the field of ss-31 peptide mitochondria research.

Due to its positive charges, SS-31 is electrostatically drawn towards the highly negative potential of the inner mitochondrial membrane. Unlike the outer mitochondrial membrane, the inner membrane is exceptionally rich in cardiolipin, an anionic phospholipid not found in abundance elsewhere. SS-31 selectively binds to cardiolipin, concentrating itself precisely where the machinery of cellular respiration resides.

Once localized, its functions are multifaceted:

Stabilizing Cardiolipin: It interacts with cardiolipin to protect it from oxidative damage and helps maintain its proper structure, which is essential for the optimal assembly and function of the electron transport chain (ETC) supercomplexes.
Electron Transport Readouts: In isolated mitochondria and cultured cells, SS-31 is reported to associate with cardiolipin and alter ETC supercomplex organization; ATP-production and ROS readouts are measured in assays.
Scavenging Reactive Oxygen Species (ROS): The dimethyltyrosine residue in SS-31 is a potent antioxidant. By positioning itself at the primary site of ROS production (Complex I and III of the ETC), it can directly scavenge superoxide radicals, reducing oxidative stress at its source.

This targeted, receptor-independent mechanism makes it a clean and specific tool for a wide range of ss-31 peptide research.

Applications in In Vitro Research Models

In the laboratory, researchers use SS-31 to investigate the role of mitochondrial dysfunction in various cell models.

Mitochondrial Respiration Assays: A common application involves incubating cultured cells (such as C2C12 myoblasts, H9c2 cardiomyocytes, or primary neurons) with SS-31, often under conditions of induced stress (e.g., hypoxia or chemical insult). Researchers then use techniques like Seahorse XF analysis to measure oxygen consumption rates (OCR), providing direct insight into how the peptide modulates mitochondrial efficiency and coupling.
ROS Measurement: To study its antioxidant effects, labs use fluorescent probes like MitoSOX Red, which specifically detects mitochondrial superoxide. By comparing ROS levels in control vs. SS-31-exposed cells under oxidative stress, researchers can quantify its scavenging activity.
Mitochondrial Membrane Potential Studies: The mitochondrial membrane potential (ΔΨm) is a key indicator of mitochondrial health. Using potentiometric dyes like TMRM or JC-1, researchers can assess if SS-31 helps stabilize the membrane potential in cells exposed to toxins or other stressors.

A Note on Experimental Protocols

A precise SS-31 protocol will always be specific to the cell type, experimental endpoint, and research question. However, some general handling guidelines apply.

Solubility: As a water-soluble peptide, ss-31 is characterized by good aqueous solubility; the appropriate laboratory solvent and conditions for a given assay are governed by the compound's chemistry and the supplier's batch-specific datasheet.
Working Concentration: The effective concentration for in vitro studies is typically in the nanomolar to low micromolar range (e.g., 1 nM to 10 µM). It is essential for researchers to perform a concentration-response curve to determine the optimal concentration for their specific cell model and assay.
Storage: The lyophilized powder should be stored at -20°C. Once in solution, the material should be aliquoted into single-use volumes and stored at -20°C or -80°C to maintain stability and avoid repeated freeze-thaw cycles.

SS-31 in the Landscape of Mitochondrial Peptides

SS-31 is a pioneering molecule in its class, but it is part of a growing field of mitochondria-targeted research peptides. Understanding its context is useful for experimental design. For instance, another peptide of significant research interest is MOTS-c. The choice between an ss-31 vs mots-c approach depends on the scientific goal; SS-31 directly modulates the bioenergetic machinery within the mitochondrion, while MOTS-c is a mitochondrially-derived peptide that signals to the nucleus to regulate gene expression and metabolic homeostasis. They represent two different ways of investigating mitochondrial function. For a side-by-side comparison, see MOTS-c vs SS-31: two mitochondria-directed peptides compared.

Related research guides

Conclusion

SS-31 (Elamipretide) is a unique aromatic-cationic tetrapeptide that offers researchers a direct and specific way to modulate mitochondrial function in vitro. Its ability to cross cell membranes and localize to the inner mitochondrial membrane allows for targeted investigations into cellular respiration, oxidative stress, and mitochondrial health. For any laboratory delving into these critical areas of cell biology, a high-purity, independently verified source of SS-31 is an indispensable tool for generating clear, reliable, and impactful data.

Sources

Birk, A. V., Liu, S., Soong, Y., et al. (2013). The mitochondrial-targeted compound SS-31 re-energizes ischemic mitochondria by interacting with cardiolipin. Journal of the American Society of Nephrology, 24(8), 1250–1261.
National Center for Biotechnology Information (2025). PubChem Compound Summary for CID 219024, Elamipretide. Retrieved July 16, 2025 from https://pubchem.ncbi.nlm.nih.gov/compound/Elamipretide.

Frequently asked questions

What is SS-31 (elamipretide)?

An aromatic-cationic tetrapeptide used as a reference compound in in vitro studies that target the inner mitochondrial membrane.

How does SS-31 target mitochondria in vitro?

It associates with cardiolipin, a lipid concentrated in the inner mitochondrial membrane, which is how it localizes to that membrane in cell models.

What is cardiolipin's role here?

Cardiolipin is the membrane lipid SS-31 binds. Its concentration in the inner mitochondrial membrane is what gives the peptide its targeting in research systems.

How is SS-31 studied in the lab?

In assays of mitochondrial membrane integrity and function in cultured cells, with appropriate controls.

Is SS-31 for research use only?

Yes, supplied for in vitro laboratory research use only.
